Overview
CELECTRON AUDIO LT-A Series is an extended range of active speaker systems with plywood cabinet offering the high quality sound and a high-level performance in an affordable package. Anti-scratch paint and steel grilles with an internal foam layer provide proper protection.For the high frequency reproduction, CELECTRON AUDIO LT-A Series have wide-dispersion horns, able to provide constant coverage for large audiences and detailed response with low distortion. The high-excursion woofers, together with carefully tuned vented cabinets, offers an extended response with deep and tight basses. The lightweight power modules used in this series feature the latest technologies for amplification. The power modules are hosted in fully-sealed die-cast aluminum boxes that provides protection, perfect insulation of the cabinet from the outside and extremely efficient cooling. Each module includes a sophisticated pre-amp section with up to 24 dB/ oct. CELECTRON AUDIO LT-A loudspeaker systems can be combined with the CELECTRON AUDIO SW-A subwoofers and capable of providing the perfect low frequency extension for each model of the series.
Features
- 2-Way Vented Enclosure With High Excursion Woofer
- Wide Dispersion Horn Designed For Wider Coverage Area
- User Friendly Simple Adjusting
- Combo Input Connector(XLR Female & ¼”) Provide Easier Installation
- Switch Mode Power Source For LT-8A, LT-10A, LT-12A, LT-15A and LT-215A
- Dual Limiter Circuit For Total Loudspeaker Protection
- Lightweight & Strong Plywood Cabinet
- Scratch Resistant Paint & Metal Grilles With Internal Foam Layer
- Dual-angle Pole Holder for LT-8A, LT-10A, LT-12A and LT-15A
- Perfect Combination with CELECTRON AUDIO SW-A/SW Series
- Flying Installation System Ready
[/su_tab]
[su_tab title=”Specification” disabled=”no” anchor=”” url=”” target=”blank” class=””]
[su_table responsive=”Yes”]
| Model | LT-6A | LT-8A | LT-10A |
|---|---|---|---|
| System Type | 2-Way vented Enclosure | 2-Way vented Enclosure | 2-Way vented Enclosure |
| High Frequency Device | 1″ neodymium tweeter | 1″ compression driver 1″ VC | 1″ compression driver 1.35″ VC |
| Low Frequency Device | 6.5″ woofer with 1″ VC | 8″ woofer with 1.5″ VC | 10″ woofer with 2″ VC |
| Angular Coverage | 60° H x 40° V | 60° H x 40° V | 60° H x 40° V |
| Total Peak Power | 400 W | 600 W | 800 W |
| HF Amplifier Power | 200 W Class AB | 100 W Class D | 100 W Class AB |
| LF Amplifier Power | 200 W Class AB | 200 W Class D | 300 W Class D |
| Frequency Response | 75Hz – 20 kHz | 70Hz – 20 kHz | 60Hz – 20 kHz |
| Processing | Analog | Analog | Analog |
| Max SPL at 1mt (Peak) | 114 dBspl | 125 dBspl | 127 dBspl |
| Crossover Frequency | 2400 Hz | 2200 Hz | 2000 Hz |
| Input Impedance | 30 kohm balanced 15 kohm unbalanced | 30 kohm balanced 15 kohm unbalanced | 30 kohm balanced 15 kohm unbalanced |
| Input Sensivity | LINE: 0/-10 dBu / MIC: -20 dBu | LINE: +4 dBu / MIC: -20 dBu | LINE: +4 dBu / MIC: -20 dBu |
| Controls | MIC/LINE, LEVEL | MIC/LINE, LEVEL, LOW, HIGH, GND. | MIC/LINE, LEVEL, LOW, HIGH, GND. |
| Connectors | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M |
| Power Supply | 230 V˜ or 120 V˜-50/60 Hz | 230 V˜ or 120 V˜-50/60 Hz | 230 V˜ or 120 V˜-50/60 Hz |
| Rated Consumption | 150 W | 200 W | 400 W |
| Construction | Plywood | Plywood | Plywood |
| Cabinet Colour | Black | Black | Black |
| Flying System | 1 x M4 top / 2 x M4 bottom | 4 x M8 top/bottom | 4 x M10 top/bottom |
| Mounting Pole | 1 x bottom | 1 x bottom, dual angle | 1 x bottom, dual angle |
| Nett Weight | 5.9 kg (13 lbs) | 8.5 kg (18.7 lbs) | 12.5 kg (27.6 lbs) |
| Dimensions (W x H x D) | 204 x 295 x 223 mm | 220 x 442 x 260mm | 340 x 515 x 310mm |
[/su_table]
[su_table responsive=”Yes”]
| Model | LT-12A | LT-15A | LT-215A |
|---|---|---|---|
| System Type | 2-Way vented Enclosure | 2-Way vented Enclosure | 2-Way vented Enclosure |
| High Frequency Device | 1″ compression driver 1.35″ VC | 1″ compression driver 1.35″ VC | 1″ compression driver 1.35″ VC |
| Low Frequency Device | 12″ woofer with 2.5″ VC | 15″ woofer with 2.5″ VC | 2x 15″ woofer with 2.5″ VC |
| Angular Coverage | 90° H x 60° V | 90° H x 60° V | 90° H x 60° V |
| Total Peak Power | 1000 W | 1200 W | 1600 W |
| HF Amplifier Power | 100 W Class AB | 150 W Class AB | 150 W Class AB |
| LF Amplifier Power | 400 W Class D | 450 W Class D | 650 W Class D |
| Frequency Response | 50 Hz – 20 kHz | 45 Hz – 20 kHz | 45 Hz – 20 kHz |
| Porcessing | Analog | Analog | Analog |
| Max SPL at 1mt (Peak) | 130 dBspl | 132 dBspl | 138 dBspl |
| Crossover Frequency | 2000 Hz | 2000 Hz | 2000 Hz |
| Input Impedance | 30 kohm balanced 15 kohm unbalanced | 30 kohm balanced 15 kohm unbalanced | 30 kohm balanced 15 kohm unbalanced |
| Input Sensivity | LINE: +4 dBu / MIC: -20 dBu | LINE: +4 dBu / MIC: -20 dBu | LINE: +4 dBu / MIC: -20 dBu |
| Controls | MIC/LINE, LEVEL, LOWm HIGH, GND. | MIC/LINE, LEVEL, LOW, HIGH, GND. | MIC/LINE, LEVEL, LOW, HIGH, GND. |
| Connectors | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M | MIC/LINE: Combo XLR-F / JACK, LINE: RCA, LINK: XLR-M |
| Power Supply | 230 V˜ or 120 V˜-50/60 Hz | 230 V˜ or 120 V˜-50/60 Hz | 230 V˜ or 120 V˜-50/60 Hz |
| Rated Consumption | 400 W | 400 W | 800 W |
| Construction | Plywood | Plywood | Plywood |
| Cabinet Colour | Black | Black | Black |
| Flying System | 4 x M10 top/bottom | 4 x M10 top/bottom | 4 x M10 top/bottom |
| Mounting Pole | 1 x bottom, dual angle | 1 x bottom, dual angle | 1 x bottom |
| Nett Weight | 16.5 kg (36.4 lbs) | 21 kg (46.3 lbs) | 34 kg (74.9 lbs) |
| Dimensions (W x H x D) | 380 x 595 x 360 mm | 448 x 670 x 410mm | 448 x 1060 x 40mm |
